Working principle of electric float level gauge

DATE:2015-06-29 00:22:33 VIEW:246次

Working principle of electric float level gauge; Reminder from the World Network of Instruments and Meters: Electric float level gauges are also a type of level gauge. Which electric float level gauges are you familiar with now? Compared with other level gauges, electric float level gauges also have their own characteristics. Below, experts from the World Network of Instruments and Meters will introduce the working principles and related knowledge of electric float level gauges.



Electric float level gauges are also a type of level gauge. Which electric float level gauges are you familiar with now? Compared with other level gauges, electric float level gauges also have their own characteristics. Below, experts from the World Network of Instruments and Meters will introduce the working principles and related knowledge of electric float level gauges.


Electric float level transmitters can be widely used for continuous measurement of various liquid levels, layered interfaces, or specific gravity in atmospheric or pressurized containers in industries such as petroleum, chemical, and pharmaceutical. Transmitters can be divided into two types based on their functions: standard and intelligent. Standard electric float level transmitter model: HUTD-B l; Intelligent electric float level transmitter model: HUTD-Z. The standard electric float level transmitter adopts advanced weighing sensing technology, making the measurement system characterized by high measurement accuracy, stable performance, and strong resistance to overload and eccentricity. The transmitter continuously converts changes in liquid level, interface, or specific gravity into 4-20mA DC standard current signal output.


At the same time, the pointer on the meter head continuously indicates the value of the measured parameter in percentage form. The output signal of the standard electric float level transmitter is remotely transmitted to the control room to achieve remote display of the measured parameters or control of the process. The HUTD-B series has a large measurement range, with a maximum of 3000mm; Exceeding 3000mm; On site indication and remote transmission compatibility; Mechanical displacement ensures good reliability, thereby improving the measurement accuracy and sensitivity of the transmitter; High temperature and high pressure resistance, strong corrosion resistance; Convenient on-site debugging, easy to inspect and maintain. The electric float level gauge works by virtue of Archimedes' law and force balance principle.
